Model No: | ||
---|---|---|
Square | : | NT-1X12DL-24S |
Mechnical Parameters: | ||
---|---|---|
Shape | : | Square |
Outer Diameter | : | 295X295MM |
Cutout Diameter | : | 270X270MM |
Material Properties: | ||
---|---|---|
Body Material | : | CRCA powder-coated housing |
Body Colour | : | White |
Diffuser Transparency |
: | ≥ 80% |
Screw Material | : | SS |
Electrical Parameters: | ||
---|---|---|
Power | : | 24Watt |
Input Voltage | : | 90-270VAC |
Power Factor | : | ≥0.95 |
THD | : | ≤10% |
Lumens Output | : | ≥ 2400 lm |
Surge | : | 2.5 KV |
Protection | : | No load, Short Circuit |
Led Parameters: | ||
---|---|---|
LED Efficacy | : | 125 lm/watt |
CCT | : | 3000K/4000K/ 5700K/6500K |
CRI | : | ≥ 80 |
LED Type | : | Mid Power |
LED Make | : | Everlight/Bridgelux/ Samsung |
